LFP battery is a kind of lithium-ion battery, which can replace lead-acid batteries and ordinary lithium batteries in many occasions. In the past few years, the application of LFP batteries has been expanded to various fields such as electric vehicles, power tools, medical care devices, and UPS.
| Dimensions | 300x280x200mm(11.8’’x11.02’’x7.87’’) |
|---|---|
| Weight | 22.5Kg(49.6lb) |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 206Ah |
LFP batteries are a class of lithium-ion rechargeable batteries based on LiFePO4 cathode material. They are especially well-suited to powering electrically driven systems, where charge and discharge rates can vary significantly. LFP cells and batteries reduce weight by increasing the electrolyte volume compared to standard Lithium-ion systems while maintaining high energy density, which is achieved by using high cell voltages (3.2–3.6 V nominal).
More than 6,000 cycles.
Charge: 0°C to +60°C
Discharge: -20°C to +60°C
50A max, please use the LiFePO4 charger to charge the battery.
50A continuous discharge current, 100A peak discharge current.
Protect the battery from high voltage, low voltage, over-charge, over-discharge, short circuit, and high temperature.
